Sourcing Poclain Ms35 Series Hydraulic Piston Motors High Torque Engine Manufacturer From China
Ningbo Helm Tower Noda Hydraulic Co., Ltd.- Type：Hydraulic Motor
- Color：Orange; Yellow; Blue; Black...
- Performance：Large Torque with Low Speed
- Hydraulic Fluid：Mineral Oil
- Package：Wooden Case
- Material：Iron
Base Info
- Model NO.：Poclain MS35 series
- Transport Package：Standard Export Packing
- Specification：Standard
- Trademark：Helmtower
- Origin：China ( Mainland )
- HS Code：8412291000
- Production Capacity：500 Sets Per Month
Description
Displacement Group
7
9
0
2
Displacement (ml/r)
2439
3143
3494
4198
Theoretical Torque at 10Mpa (N.m)
3978
4997
5555
6675
Rated Speed (r/min)
100
80
80
63
Rated Pressure (Mpa)
25
25
25
25
Rated Torque (N.m)
8000
10300
11450
13800
Max. Pressure (Mpa)
31.5
31.5
31.5
31.5
Max. Torque (N.m)
9850
12700
14150
17000
Speed Range (r/min)
0-125
0-125
0-100
0-100
Max. Power (kw)
Standard displacement is 110KW,variable displacement priority rotation 73KW,no priority is 55KW
