• Model NO.：BM1
• Type：Orbital Type
• Material：Steel
• Model：Bm1 Series
• Replace for：Danfoss Omp Series,M+S Epm Series,Eaton H,T Series
• Displacement：25cc - 400cc,Rev
• Pressure：up to 225bar
• Transport Package：Plywood Case
• Specification：25cc - 400cc,rev
• Trademark：Bonny
• Origin：China
• Production Capacity：100sets,Month

Replace for

Danfoss OMP Series

M+S EPM Series

EATON H/T Series

Displacement

25cc - 400cc/rev

Speed

0-1500rpm

Pressure

up to 225bar

We are the specialized manufacturer of orbital hydraulic motor. We can provide more than 2000 kinds of motor with different models and technical parameters: the rated displacement from 50mm to 1600cc, Max. torque from 50N.m to 3300N.m, Max. output power from 2 KW to 90 KW, which has provided wide choice to meet customer's needs. Meanwhile, Our products manufactured can be completely interchanged with SAUER DANFOSS OMP, OMR, OMH, OMS, OMT AND OMV series.

Features
1.Advanced manufacturing devices for the Gerotor gear set, which use low pressure of start-up, provide smooth, reliable operation and high efficiency.
2.Shaft seal can bear high pressure of back and the motor can be used in parallel or in series.
3.Special design in the driver-linker and prolong operation life.

4.Advanced design in disc distribution flow, which can automatically compensate in operating.
5.The output shaft adopts in tapered roller bearings that permit high axial and radial forces. The case can offers capacities of high pressure and high torque in the wide of applications.
6.Various kinds of flange, output shaft and oil port mounting dimension.
