• Model NO.：4SDCV80-35 Truck mounted crane control valve
• HS Code：8481804090
• Production Capacity：2000,Month

Basic Info.

Model NO. 4SDCV80-35 Truck mounted crane control valve HS Code 8481804090 Production Capacity 2000/Month

Product Description

DCV Series Directional Control Valve Group for truck mounted crane,Flow Sharing Control Valve,Multiple Directional Control Valves
This product is applicable to special vehicles like truck mounted crane, wrecker, scrubbing machine and dynamic compactor and can effectively control such actuating mechanisms like motor and oil cylinder.

Functions and features
1. Compact size, light and handy structure, small weight, simple operation and safety & reliability;
2. Work group number can be added according to demand, 8 spools at most.
3. Complete configuration of primary and secondary overflow valves; Opening pressure to be adjusted as required by customers;
4. Series-parallel connection structure and external load retaining valve ensure that the actuating mechanism with higher load will not fall in operation.
5. Modules with different functions on the valve group can realize the switchover between single and dual pumps to improve working efficiency and save energy consumption.

Basic datasheet:
1. Max. Working pressure: 35MPa;
2. Rated Flow: 80L/min;
3. flow rate option:40L/min; 60L/min; 80L/min; 120L/min;160L/min;
3. Operation mode: Hydraulic, manual, manual + mechanical limit and pneumatic control (for flow below 80L/min).

4SDCV80-35 dimensions

4SDCV80-35 symbols
This valve have been supply to Palfinger,SANY,,Zoomlion etc.
This valve is design for our current customer,it's most popular on truck mounted crane.
Yuzhou have own R&D department,we can special design the valves for your application.
Choosing YUZHOU hydraulic is choosing high quality!
