China Manufacture Low Speed High Torque Omm/Hmm/Bmm Orbit Hydraulic Motor Manufacturer
Jining Jinjia Hydraulic Co., Ltd.- Certification：ISO9001
- Excitation Mode：Excited
- Power Rating：Other
- Casing Protection：Other
- Number of Poles：Other
- Speed：Low Speed
Base Info
- Model NO.：HMM
- Type：Other
- Warranty：1 Year
- Color：Customer′s Request
- Max Torque(N*M)：Contin 11-46 N*M
- Output Power：Contin1.8~2.4kw
- Motor of Material：Cast Iron
- Place of Origin：Shandong, China
- Transport Package：Wooden Packing
- Specification：3kg
- Trademark：jinjia
- Origin：Jining
- Production Capacity：5000set,Month
Description
Torque(N*m)
Continuous
11
16
25
40
45
46
Intermittent
15
23
35
57
70
88
1.Intermittent means the entrance of the maximum pressure;continuous working pressure means the differential pressure.
2.Motor should not work under the highest pressure and the maximum speed.
3.The running time should not exceed 10% under interoittent working conditions.
4.The maximum working temperature is 80°.
5.The maximum allowable back pressure is 10MPa,but the recommended back pressure should not exceed 5MPa.a leaking pipes is needed when exceeding.
6.One hour running time under 40% of maximum working pressure is recommended before full capacity working.
7.Recommending N68 anti-wear hydraulic oil,viscosity37-73cSt,cleanliness ISO18/13.
Product Application
OMM/OML/HMM/BMM Series Orbital Hydraulic Motor with its shell made of ductile cast iron of adequate intenty, can be applicated to situations with less and interval operation,widely to agriculture, forestry.plastic
machine tools and minmanchines etc.
