Eaton Hydraulic Motor for Hydraulic Rotary Drilling Rig
Ningbo Kingbonny Machinery Imp. & Exp. Co., Ltd.- Certification：ISO9001
- Excitation Mode：Hydraulic Motor
- Power Rating：Hydraulic Motor
- Casing Protection：Protection Type
- Number of Poles：Hydraulic Motor
- Speed：0-1500rpm
Base Info
- Type：Orbital Hydraulic Motor
- Material：Steel
- Model：Bm1 Series
- Replace for：Danfoss Omp Series,M+S Epm Series, Eaton H,T Seri
- Displacement：28cc - 355cc,Rev
- Transport Package：Plywood Case
- Specification：25cc - 400cc,rev
- Trademark：Bonny
- Origin：China
- Production Capacity：100sets,Month
Description
Motor Size
50
60
80
100
125
160
200
250
315
400
500
Interchangeable
OMP50
OMP60
OMP80
OMP100
OMP125
OMP160
OMP200
OMP250
OMP315
OMP400
OMP500
Displacement cc/r
50
63
80
100
125
160
200
250
320
400
500
Flow
LPM
continuous
38
45
57
57
57
57
57
57
57
57
57
intermittent
45
53
68
68
68
68
68
68
68
68
68
Speed
RPM
continuous
698
663
679
558
452
354
284
235
178
145
115
intermittent
859
774
811
669
544
425
339
281
208
171
136
Pressure
Bar
continuous
124
124
124
124
124
115
110
100
90
90
83
intermittent
138
138
138
138
138
124
124
124
124
110
90
Torque
Nm
continuous
73
86
124
154
194
228
285
304
364
466
496
intermittent
84
93
139
173
216
261
319
378
403
522
516
Features
1. Adopt axial piston oil distributing, compact volume, high pressure and speed.
2. Using sphere oil distributing, High volume and working efficiency.
3. Adjustable displacement, enhancing the output speed at small angle.
4. Reversible rotating orientation, radial and axial load available.
5. Can be using as a pump in some close system.
6. Complete interchange with Rexroth A6VM series bent axial piston hydraulic motor on performance and dimensions.
