Low Speed Large Torque Gerotor Hydraulic Motor Omt800

Dongguan Blince Machinery & Electronics Co., Ltd.
  • Power Rating：3500W
  • Speed：Low Speed
  • Type：Hydraulic Power Units
  • Displacement(Cc/Rev)：160~800
  • Continuous Max Speed(Rpm)：625~154
  • Continuous Max Torque(N.M)：470~1464

Base Info

  • Model NO.：OMT800 Series Hydraulic Motor
  • Max Pressure(MPa)：20
  • Cylinde Parallel Shaft Size：40mm
  • Hole Middle Distance：160mm
  • Ports and Drain Port：G1,4, G3,4
  • Flange：Standard 4 Hole Diamond Flange
  • Material：Rust-Proof Cast Iron
  • Warranty：One Year
  • Hydraulic Power Units：Hydraulic Motor
  • Transport Package：Sale Packing Contians Carton or Wood Case
  • Specification：CE
  • Trademark：Blince
  • Origin：Guangdong Province, China (Mainland)
  • Production Capacity：1000 Per Month

Description

Type OMT
160OMT
200OMT
230OMT
250OMT
315OMT
400OMT500OMT
630OMT
800Displacement (cc/rev)161.1
 201.4232.5251.8326.3410.9523.6629.1801.8Max torque
(n.m)cont4705906707309501080122013181464int56071082188011401260137014981520Max pressure
(Mpa)cont202020202018161412.5int242424242421181613Max speed )cont625625536500380305240196154int780750643600460365285233185Max flow
(L/min)cont100125125125125125125125125int125150150150150150150150150Weight(kg)19.52020.420.52122232425
