Male Jic/Male Jic to Male Pipe Run Tee Adapter Ajnj
YUYAO RUIFENG HYDRAULIC CO., LTD.- Pressure：High Pressure
- Work Temperature：High Temperature
- Feature：Heat-Resistant
- Material：Carbon Steel
- Size: 4,6,8,10,12,16,20,24,32：Raw Material : Carbon Steel, Ss Steel
- Type：Hydraulic Power Units
Base Info
- Model NO.：AJNJ
- Auxiliary Components：Pipe and Pipe Fittings
- Transport Package：Plastic Bag+Box +Pallet
- Specification：SGS
- Trademark：OEM OR NO BRAND
- Origin：Ningbo, China
- HS Code：73079200
- Production Capacity：100000PCS,Month
Description
P/N | T1(UNF-2A) | L1 | T2(NPTF) | L2 | T3(UNF-2A) | L3 | Y FLATS |
2605-03-02-03 | 3/8-24 | 0.83 | 1/8-27 | 0.72 | 3/8-24 | 0.83 | 0.438 |
2605-04-02-04 | 7/16-20 | 0.89 | 1/8-27 | 0.78 | 7/16-20 | 0.89 | 0.438 |
2605-04-04-04 | 7/16-20 | 1.05 | 1/4-18 | 1.09 | 7/16-20 | 1.05 | 0.562 |
2605-05-02-05 | 1/2-20 | 0.95 | 1/8-27 | 0.78 | 1/2-20 | 0.95 | 0.562 |
2605-05-04-05 | 1/2-20 | 1.05 | 1/4-18 | 1.09 | 1/2-20 | 1.05 | 0.562 |
2605-06-02-06 | 9/16-18 | 1.06 | 1/8-27 | 0.9 | 9/16-18 | 1.06 | 0.562 |
2605-06-04-04 | 9/16-18 | 1.06 | 1/4-18 | 1.09 | 7/16-20 | 1.05 | 0.562 |
2605-06-04-06 | 9/16-18 | 1.06 | 1/4-18 | 1.09 | 9/16-18 | 1.06 | 0.562 |
2605-06-06-06 | 9/16-18 | 1.14 | 3/8-18 | 1.22 | 9/16-18 | 1.14 | 0.75 |
2605-06-08-06 | 9/16-18 | 1.22 | 1/2-14 | 1.47 | 9/16-18 | 1.22 | 0.875 |
2605-08-04-08 | 3/4-16 | 1.25 | 1/4-18 | 1.22 | 3/4-16 | 1.25 | 0.75 |
2605-08-06-06 | 3/4-16 | 1.25 | 3/8-18 | 1.22 | 9/16-18 | 1.25 | 0.812 |
2605-08-06-08 | 3/4-16 | 1.25 | 3/8-18 | 1.22 | 3/4-16 | 1.25 | 0.75 |
2605-08-08-06 | 3/4-16 | 1.25 | 1/2-14 | 1.22 | 9/16-18 | 1.25 | 0.813 |
2605-08-08-08 | 3/4-16 | 1.33 | 1/2-14 | 1.47 | 3/4-16 | 1.33 | 0.875 |
2605-08-12-08 | 3/4-16 | 1.42 | 3/4-14 | 1.59 | 3/4-16 | 1.42 | 1.062 |
2605-10-08-10 | 7/8-14 | 1.45 | 1/2-14 | 1.47 | 7/8-14 | 1.45 | 0.875 |
2605-10-12-10 | 7/8-14 | 1.54 | 3/4-14 | 1.59 | 7/8-14 | 1.54 | 1.125 |
2605-12-08-12 | 1 1/16-12 | 1.66 | 1/2-14 | 1.59 | 1 1/16-12 | 1.66 | 1.25 |
2605-12-12-08 | 1 1/16-12 | 1.66 | 3/4-14 | 1.59 | 3/4-16 | 1.42 | 1.062 |
2605-12-12-12 | 1 1/16-12 | 1.66 | 3/4-14 | 1.59 | 1 1/16-12 | 1.66 | 1.062 |
2605-14-12-12 | 1 3/16-12 | 1.8 | 3/4-14 | 1.69 | 1 1/16-12 | 1.77 | 1.312 |
2605-14-12-14 | 1 3/16-12 | 1.8 | 3/4-14 | 1.69 | 1 3/16-12 | 1.8 | 1.312 |
2605-16-12-16 | 1 5/16-12 | 1.81 | 3/4-14 | 1.78 | 1 5/16-12 | 1.81 | 1.375 |
2605-16-16-16 | 1 5/16-12 | 1.81 | 1-11 1/2 | 1.97 | 1 5/16-12 | 1.81 | 1.312 |
2605-20-20-20 | 1 5/8-12 | 2.06 | 1 1/4-11 1/2 | 2.38 | 1 5/8-12 | 2.06 | 1.625 |
2605-24-24-24 | 1 7/8-12 | 2.33 | 1 1/2-11 1/2 | 2.64 | 1 7/8-12 | 2.33 | 1.875 |
2605-32-32-32 | 2 1/2-12 | 3.06 | 2-11 1/2 | 3 | 2 1/2-12 | 3.06 | 2.5 |
