Blince Bmrs 36/50/80/100/125/160/200/250/315/375cc Hydraulic Motor
Dongguan Blince Machinery & Electronics Co., Ltd.- Certification：GS, RoHS, CE, ISO9001
- Excitation Mode：Compound
- Power Rating：2500W
- Casing Protection：Protection Type
- Number of Poles：6
- Speed：High Speed
Base Info
- Model NO.：Eaton S series 103-xxxx-xxx orbital motor
- Type：Gear Type
- Structural：Hydraulic Orbit Motor
- Flange Type：Rhomb-Flange,Square-Flange
- Shaft Type：Parallel Key,Splined Tooth
- Place of Origin：Guangdong, China (Mainland)
- Application：Medium and Low Duty Tasks
- Hydraulic Power Units：Vane Pump
- Usage：Hydraulic Oil
- Material：Cast Iron
- Flow Distribution：Axial Distribution Type
- Diameter of Shaft：25mm,25.4mm
- Transport Package：Plastic Tube +Carton+Wooden Pallets
- Specification：ISO9001
- Trademark：Blince
- Origin：Guangdong, China (Mainland)
- HS Code：8412291000
- Production Capacity：1000 Sets Per Month Meet Your Requirment
Description
Type OMRS
36 OMRS
50 OMRS
80 OMRS
100 OMRS
125 OMRS
160 OMRS
200 OMRS
250 OMRS
315 OMRS
375 Displacement
(cc/rev) 36 51.7 81.5 102 127.2 157.2 194.5 253.3 317.5 381.4 Max speed
(rpm)
cont 1250 960 750 600 475 378 310 240 190 155 int 1520 1150 940 750 600 475 385 300 240 190 Max torque
(N/m) cont 72 100 195 240 300 360 360 390 390 365 int 83 126 220 280 340 430 440 490 535 495 peak 105 165 270 320 370 460 560 640 650 680 Max. output (kW) cont 8.5 9.5 12.5 13.0 12.5 12.5 10.0 7.0 6.0 5.0 int 9.8 11.2 15.0 15.0 14.5 14.0 13.0 9.5 9.0 8.0 Max
Pressure
drop
(Mpa) cont 14.0 14.0 17.5 17.5 17.5 16.5 13 11 9.0 7.0 int 16.5 17.5 20 20 20 20 17.5 15 13 10 peak 22.5 22.5 22.5 22.5 22.5 22.5 22.5 20 17.5 15 Max flow
(L/min) cont 40 50 60 60 60 60 60 60 60 60 int 45 60 75 75 75 75 75 75 75 75 Net Weight (kg) 6.5 6.7 6.9 7.0 7.3 7.6 8.0 8.5 9.0 9.5
The Blince OMRS motors are used in the following application areas:
* Construction equipment
* Agricultural equipment
* Material handling & Lifting equipment
* Forestry equipment
* Lawn and turf equipment
* Special purpose
* Machine tools and stationary equipment
* Marine equipment
* And more
Warranty
1. Guarantee for one year or 1000 hours (according to whichever ends first) from the purchasing date on.
2. During the guarantee period, our company will provide the easy-damaged spare parts for problems
Caused by our quality of production or raw material. Pls provide the defective appearance and related invoice number.
3. Sorry for you should responsible for the freight come-and-go, and the custom tax.
4. After expiration, our company can provides cost spare-parts maintenance for engines.
5. To save the cost, you can choose send the motor back without packing.
6. My dear friend, your emails can be get within one business day. If you do not receive our reply, please kindly re-sent your email or give us a call any time.
Welcome enquiry us!
Amy chen
THANKS FOR YOUR READING, AND HOPE YOU HAVE A NICE DAY. ( n. N ) **
