• Model NO.：poclain MS18 MSE18
• Type：Hydraulic Motor
• Series：Ms18 Mse18
• Brand：Helm Tower
• Place of Original：China Mainland
• Color：Customized
• Performance：Large Torque with Low Speed
• Hydraulic Valve：Proportional Control Valve
• Auxiliary Components：Seal
• Hydraulic Fluid：Synthetic Hydraulic Oil
• Flow Control Valve：Adjusting Valve
• Pressure Control Valve：Overflow Valve
• Hydraulic Control Unit：Selector Valve
• Hydraulic Motor：Piston Hydraulic Motor
• Hydraulic Actuator：Hydraulic Cylinder Piston
• Hydraulic Power Units：Piston Pump
• Transport Package：Export Wooden Case
• Specification：CE
• Trademark：Helm Tower`
• Origin：China Mainland
• HS Code：84129090
• Production Capacity：500 PCS Per Month

Displacement Group
8
9
0
1
2
Displacement (ml/r)
1395
1571
1747
1911
2099
Theoretical Torque at 10Mpa (N.m)
2218
2498
2778
3038
3337
Rated Speed (r/min)
100
100
100
80
80
Rated Pressure (Mpa)
25
25
25
25
25
Rated Torque (N.m)
4550
5150
5700
6250
6900
Max. Pressure (Mpa)
31.5
31.5
31.5
31.5
31.5
Max. Torque (N.m)
5650
6350
7050
7700
8500
Speed Range (r/min)
0-125
0-125
0-125
0-100
0-100
Max. Power (kw)
Standard displacement is 70KW,variable displacement priority rotation 47KW,no priority is 35KW

MSE18 Technical Data:
Displacement Group
0
1
2
Displacement (ml/r)
2340
2560
2812
Theoretical Torque at 10Mpa (N.m)
3721
4078
4471
Rated Speed (r/min)
63
63
50
Rated Pressure (Mpa)
25
25
25
Rated Torque (N.m)
7650
8400
9200
Max. Pressure (Mpa)
31.5
31.5
31.5
Max. Torque (N.m)
9450
10350
11400
Speed Range (r/min)
0-80
0-80
0-63
Max. Power (kw)
Standard displacement is 70KW,variable displacement priority rotation 47KW,no priority is 35KW


For instance:
- BELL 220A Telelogger
- HAMM 4011 Road Roller
- BOMAG 211 Soil compactor
- BOMAG 130 AD Road Roller
- BOMAG Roller BW213 D2
- Carterpillar 226B
- Carterpillar CS-563 compactor
- John Deere 280 skid steer,
- BOBCAT T190 skid steer and excavators
- VERMEER Horizontal Directional Drill
- SANDVIK Machine
- Gehl 6635 Skid steer
- Greenbeans and pea Harvesting Machine(PMC-979-AT)
