Poclain Hydraulic Motor Ms02 Mse02 Made in China
Ningbo Helm Tower Noda Hydraulic Co., Ltd.- Number of Poles:2
- Type:Hydraulic Motor
- Series:Poclain Motor Ms02 Mse02
- Place of Original:China Mainland
- Color:Yellow, Blue, Black, Orange, Gray
- Performance:Large Torque with Low Speed
Base Info
- Model NO.:MS02 MSE02
- Brand:Helm Tower
- Hydraulic Valve:Proportional Control Valve
- Auxiliary Components:Seal
- Hydraulic Fluid:Synthetic Hydraulic Oil
- Flow Control Valve:Adjusting Valve
- Pressure Control Valve:Overflow Valve
- Hydraulic Control Unit:Selector Valve
- Hydraulic Motor:Piston Hydraulic Motor
- Hydraulic Actuator:Hydraulic Cylinder Piston
- Hydraulic Power Units:Piston Pump
- Transport Package:Standard Export Wooden Case.
- Specification:CE, SGS
- Trademark:Helm Tower
- Origin:Ningbo, China
- HS Code:8412291000
- Production Capacity:500 Sets Per Month
Description
Type
DisplacementMS02-8 MS02-9 MS02-0 MS02-1 MS02-2 Full/Semi Full/Semi Full/Semi Full/Semi Full/Semi Displacement(ml/r) 172 86 213 106 235 118 255 128 Max power(kw) 16 10 16 10 16 10 16 10 Pressure discrepancy 10MPa Torque
(N. m) 273 136 340 170 351 175 405 202 Rated torque(N. m) 643 796 878 953 Rated pressure(MPa) 25 25 25 25 Max pressure(MPa) 40 40 40 35 Rated speed(r/min) 140 140 140 120 Speed range(r/min) 0-310 0-310 0-310 0-260
Displacement
(N. m)
features:
-- High performance rotary group with well-proven spherical control area offering the following advantages, self-centering.
-- Low periph-eral speed
-- High efficient.
-- Long service life robust rolling bearing.
-- Drive shaft will support radial loads.
-- Low noise level.
-- High duty roller bearing for intermettent high pressure operation.
-- For continuous duty hydrostatic are availabe.
-- Excellent starting characteristics.
-- High power density
-- Optional mounting position
Our advantages:
- High performance:The performance of our motor is very close to Poclain & Rexroth original motors, even sometimes be superior to original motor.
- 100% interchangeable:Both complete motor and spare parts, our products could completely replace to Poclain & Rexroth original motors.
- Reasonable price:In the spirit of win-win principle, our price system has been settled much lower than Poclain & Rexroth original motors.
- Fast delivery time:Most of the spare parts we have inventory, so that we can keep the delivery time within 10 days for regular motor.
- Excellent aftersales service:we have 12 months' quality warranty, and within warranty time ,all repairment are free of charg.
