• Model NO.：BMP36,50,80,100,125,160,200,250,315,400,500cc
• Application：Medium and Low Duty Tasks
• Stock：Rich
• Hydraulic Valve：Proportional Control Valve
• Hydraulic Motor：Piston Hydraulic Motor
• Hydraulic Actuator：Combination Hydraulic Cylinders
• Hydraulic Power Units：Vane Pump
• Transport Package：Plastic Tube +Carton+Wooden Pallets
• Specification：ISO9001
• Trademark：Blince
• Origin：Guangdong, China (Mainland)
• HS Code：8412291000
• Production Capacity：1000 Sets Per Month Meet Your Requirment

TypeBMP
36BMP
50BMP
80BMP
100BMP
125BMP
160BMP
200BMP
250BMP
315BMP
400BMP
500Geometric displacement
(cm3/rev.)3651.777.796.2120.2157.2194.5240.3314.5389.5486.5Max.speed  (rpm)con.15001150770615490383310250192155120 int.16501450960770615475385310240190150Max.torque (N.m)cont.55100146182236302360380375360385 int.76128186227290370440460555525560 peak96148218264360434540550650680680Max.output  (KW)cont.8.010.010.011.010.010.010.08.57.06.05.0 int.11.512.012.013.012.012.012.010.58.57.06.0Max.pressure
Drop   (Mpa)cont.12.5141414141414119.07.06.0 int.16.517.517.517.517.517.517.5141410.59.0Max.flow  (L/min)cont.5560606060606060606060 int.6075757575757575757575Net Weight(kg)5.65.65.75.96.06.26.46.76.97.48.0
Blince BMP series high speed orbital motors with low torque.
Key data:
1. Displacement range 36 to 500 cc
2. Speed up to 1650rpm/min
3. Torque up to 680N? M
4. Output up to 13.0kW
5. Pressure drop up to 22.5MPa (225bar)
3. Flow up to 75 l/min [19.8 US gal/min]
4. Pilot diameter Ø 82.5 [3.25 in]
5. Mounting flnge A2/A4
6. Output shaft Ø 25mm / Ø 32mm / Ø 25.4mm / Ø 31.75mm / Ø 28.56mm cylindrical shaft
[1 inch cylindrical shaft]
7. Port connection G1/2 [4× M8, G1/4] / M22× 1.5[4× M8, M14× 1.5] / 7/8-14[4X5/16-18UNC, 7/16-20UNF] /
1/2-14 [4X5/16-18UNC, 7/16-20UNF] / PT(RC)1/2, PT(RC)1/4 [4xM8]

Features:
1. High pressure shaft seal
2. Proven orbital motor design
3.3-chamber motor design
4. Suitable for medium and low duty

Benefis:
1. High power density
2. High effiency
3. High constant quality
4. Reliable

Blince BMP high speed motors are used in the following application areas:
1. Sweeper
2. Winch
3. Conveyor
4. Crane
5. Aerial lift
6. Combine Harvester
7. Seeder
8. Spreader
9. Auger
10. Machine tool
11. And more

BLINCE BMP HYDRAULIC MOTOR CAN SUBSTITUE FOR:
Sauer Danfoss OMP series
White Drive Product WP/155 Series
White Drive Product WG/275/277/280 Series
M+S Motor MP/MLHP Series
Brewin( SAMHYDRAULIK) BG Series
Japen OPN ORB-GS Series
