• Model NO.：M7F, M7G, M7V, M7H
• Origin：China
• HS Code：8413606090
• Production Capacity：50

Basic Info.

Model NO. M7F, M7G, M7V, M7H Origin China HS Code 8413606090 Production Capacity 50

Product Description

[Features]

Fix / Variable Displacement Motors
Size
Maximum
Displacment Torque Maximum Pressure (bar) Maximum Speed (rpm)
(ml / rev) (N.m / bar) Intermittent Continuous Case 100% displacement 50% displacement
M6 98.3 1.57
420 345 5.20 3000 3600
M7 118.8 1.89
M11 180.3 2.87
420 345 5.20 2400 2800
M14 229.5 3.62
M24 403.2 6.23 345
345 5.20
2100 2100
M30 501.5 7.97 345 1800 1800
M6 -98 cc/rev, M7 -119 cc/rev,
M11-180 cc/rev, M14 -229 cc/rev,
M24 -403 cc/rev, M30 -500 cc/revFunction: Features:
• 6 displacements 98cc/rev - 500 cc/rev
• Pressure to 420 Bar
• Speed to 3600 RPM
• Fixed and variable
• Low noise levels
• Wide variety of control options
• Hot Oil Shuttle option
• System Flexibility
Please Note: Code out Overleaf
2/ Variable Displacement
Hydrostatic Motors Goldcup Series Transmission
• Goldcup fixed and variable transmission
motors are suitable for the most demanding
applications.
• Mounts and shaft options are standard SAE.
• Controls on variable motors include 2 speed
or proportional hydraulic stroker with
secondary reverse compensator an option.
•
•
M6 / M7 fixed motors are available with
cam options to reduce the displacement of
standard motors.
Both types of motor can be fitted with hot
oil shuttle with or without orifices to limit
the oil taken from the transmission loop.[Products]
