• Model NO.：060
• Max Back Pressure：2.1MPa
• Input Torque：1.7-2.5nm
• Max System Temperature：93
• Oil Filtration：ISO19,16
• Type：Hydraulic Control Unit
• Hydraulic Valve：Setpoint Control Valve
• Auxiliary Components：Seal
• Hydraulic Fluid：Synthetic Hydraulic Oil
• Flow Control Valve：Adjusting Valve
• Pressure Control Valve：Pressure Relay
• Hydraulic Control Unit：Check Valve
• Hydraulic Motor：Piston Hydraulic Motor
• Hydraulic Actuator：Hydraulic Cylinder Piston
• Hydraulic Power Units：Piston Pump
• Transport Package：in Carton or Plywoodcase
• Specification：50
• Trademark：hyphen
• Origin：China
• HS Code：87089490
• Production Capacity：500000

Basic Info.

Model NO. 060 Max Back Pressure 2.1MPa Input Torque 1.7-2.5nm Max System Temperature 93 Oil Filtration ISO19/16 Type Hydraulic Control Unit Hydraulic Valve Setpoint Control Valve Auxiliary Components Seal Hydraulic Fluid Synthetic Hydraulic Oil Flow Control Valve Adjusting Valve Pressure Control Valve Pressure Relay Hydraulic Control Unit Check Valve Hydraulic Motor Piston Hydraulic Motor Hydraulic Actuator Hydraulic Cylinder Piston Hydraulic Power Units Piston Pump Transport Package in Carton or Plywoodcase Specification 50 Trademark hyphen Origin China HS Code 87089490 Production Capacity 500000

Product Description

050 Series:
Small displacement series
Include: Open center and load sensing style
Displacement: 50/63(ml/r)

050 series PSU is a small displacement PSU.
The displacement includes: 50.63ml/r. It is typical used in mini engineering vehicles, such as small tractor.

Features:
1. The optimum design of spool and sleeve gains better characteristics.
2. Special casting design for low pressure drop.
3. Basic system open center.

Main Specification Data:
Max. System pressure-16Mpa
Max. Back pressure-2.1MPa
Input torque-1.7~2.5Nm
Max. System operating temperature-93° C

Recommended oil filtration-ISO19/16
