Hydraulic Parts

Home > Product > Hydraulic Motor

Hydraulic Piston Motor Axial Piston Fixed Motors (A2FM28)

Wuxi Hyphen Technology Co., Ltd.
  • Speed：High Speed
  • Type：Hydraulic Motor
  • Transport Package：in Plywood Case
  • Trademark：HYPHEN
  • Origin：China

Base Info

  • Model NO.：A2FM28
  • HS Code：8412299090
  • Production Capacity：50000PCS,Year

Description

Basic Info.

Model NO. A2FM28 HS Code 8412299090 Production Capacity 50000PCS/Year

Product Description

Hydraulic Piston Motor Axial Piston Fixed Motors (A2FM28)

Axial Piston Fixed Motors, High Speed Hydraulic Motor,
Nominal Pressure 400bar, Peak Pressure 450bar, Used Open and Closed Circuit.
FKM seals, Parallel Keyed Shaft DIN6885, 4Hole flange, SAE Flange Ports, Rear.

Axial piston unit of bent axis design with fixed displacement for use as either pump or motor in hydrostatic drive, in open or closed circuit.
Operated as a pump, the flow is proportional to the drive speed and displacement.

Operated as a motor, the output speed is proportional to the volume and inversely proportional to displacement.
The output torque increase with the pressure drop between the high and low pressure sides.
Light weight, long life time.
