Blince Bmm20/Omm20 Hydraulic Motor for Hydraulic Tapping Machine
Dongguan Blince Machinery & Electronics Co., Ltd.- Certification：CE, ISO9001
- Excitation Mode：Excited
- Power Rating：2500W
- Casing Protection：Protection Type
- Number of Poles：6
- Speed：High Speed
Base Info
- Model NO.：BMM,OMM8,12.5,20,32,40,50 Hydraulic Motor
- Type：Hydraulic Motor
- Structural：Hydraulic Cycloid Motor,Hydraulic Orbit Motor
- Usage：Hydraulic Oil
- Material：Cast Iron
- Flow Distribution：Axial Distribution Type
- Shaft Type：Parallel Key, Involute Key Shaft
- Diameter of Shaft：16mm,15.875mm,16.5mm Staright
- Port Type：Side Port,End Port
- Place of Origin：Guangdong, China (Mainland)
- Hydraulic Power Units：Vane Pump
- Hydraulic Motor：Hydraulic Cycloid Motor,Hydraulic Orbit Motor
- Transport Package：Plastic Tube +Carton+Wooden Pallets
- Specification：ISO9001
- Trademark：Blince
- Origin：Guangdong, China (Mainland)
- HS Code：8412291000
- Production Capacity：1000 Set,Sets Per Month Meet Your Requirment
Description
TypeOMM
8 OMM
12.5 OMM
20 OMM
32 OMM
40 OMM
50 Geometric
displacement (cm³/rev.)
8.2
12.9
19.9
31.6
39.8
50.3 Max.speed
(rpm) cont. 1950 1550 1000 630 500 400 int. 2450 1940 1250 800 630 500 Max. torque
(Nm) cont. 11 16 25 40 45 46 int. 15 23 35 57 70 88 peak 21 33 51 64 82 100 Max.output
(kW) cont. 1.8 2.4 2.4 2.4 2.2 1.8 int. 2.6 3.2 3.2 3.2 3.2 3.2 Max. pressure
drop
(MPa) cont. 10 10 10 10 9 7 int. 14 14 14 14 14 14 Peak 20 20 20 16 16 16 Max.
flow (L/min) cont. 16 20 20 20 20 20 int. 20 25 25 25 25 25 Max.inlet pressure (MPa) cont. 17.5 int. 22.5 Net Weight (kg) 1.9 2 2.1 2.2 2.3 2.4
