High Pressure Hydraulic Double Gear Oil Pump Hydraulic Power Unit Cbwlgy1-G322/B310-CF1X
HEFEI CHANGYUAN HYDRAULIC CO., LTD.- Certification：ISO9001
- Pressure：High Pressure
- Work Temperature：Normal Temperature
- Installation：Vertical
- Material：Aluminum Alloy
- Product Name：Hydraulic Double Gear Pump
Base Info
- Model NO.：CBWLGY1-G322,B310-CF1X
- Nominal Displacement：22,10 Ml,R
- Rated Pressure：250,25 Bar
- Maximum Pressure：300,63 Bar
- Minimum Speed：800 Rpm
- Rated Speed：2500 Rpm
- Maximum Speed：3000 Rpm
- Volume Efficiency：92 %
- Warranty：1 Year
- Certificate：ISO9001:2008
- Transport Package：Packed in Export Standard
- Trademark：HCHC
- Origin：Anhui, China
- Production Capacity：8000 Sets Per Month
Description
Volume Efficiency
(≥%)
