Hydro Leduc Series Hydraulic Motor (FIXED DISPLACEMENT) Mxp Motor
Wuhan Xin Lai Fu Hydraulic Pneumatic Equipment Co., Ltd.- Certification：GS, RoHS, CE, ISO9001
- Excitation Mode：Compound
- Power Rating：3500W
- Casing Protection：Open Type
- Number of Poles：12
- Speed：High Speed
Base Info
- Model NO.：MXP Motor
- Type：Plunger Type
- Warranty：One Year
- Original：Yes
- Application：Machinery Field
- Port：Shanghai
- Factory：Chinese Goods
- Stock：in Stock
- High Quality：Hot Sale Good Quality
- Structure：Control
- Material：Casting
- Media：Oil
- Brand Name：Hydro Leduc
- Transport Package：Box and Carton Package
- Specification：hydraulic
- Trademark：XLF
- Origin：China
- HS Code：8412291000
- Production Capacity：1600sets,Month
Description
These motors are built with DIN flange and shaft.
| MXP Motor | 25 | 32 | 41 | 50 | 63 | 80 | 108 | 126 | |
| Displacement | cc | 25 | 32 | 41 | 50.3 | 63 | 80.4 | 108.3 | 126 |
| Continuous max. speed | rpm | 6300 | 6300 | 5600 | 5000 | 5000 | 4500 | 4000 | 3400 |
| Intermittent max. speed | rpm | 6900 | 6900 | 6200 | 5500 | 5500 | 5000 | 4400 | 4400 |
| Max flow absorbed | l/mn | 158 | 202 | 230 | 252 | 315 | 362 | 435 | 428 |
| Torque / bar | N.m/bar | 0.4 | 0.5 | 0.65 | 0.8 | 1 | 1.27 | 1.7 | 2 |
| Torque at 350 bar | N.m | 140 | 175 | 227 | 280 | 350 | 445 | 595 | 700 |
| Mini/maxi motor temperature | °C | −25 / 110 | −25 / 110 | −25 / 110 | −25 / 110 | −25 / 110 | −25 / 110 | −25 / 110 | −25 / 110 |
| Max. pressure continuous/peak | bar | 400 / 450 | 400 / 450 | 400 / 450 | 400 / 450 | 400 / 450 | 400 / 450 | 400 / 450 | 400 / 450 |
| Dimensions (mm) | A | 171.5 | 177.7 | 177.7 | 189.3 | 189.3 | 216.2 | 216.2 | 218.5 |
| B | 71.9 | 77 | 77 | 86.8 | 86.8 | 99.5 | 99.5 | 101.43 | |
| C | 103.9 | 109.1 | 109.1 | 118.9 | 118.9 | 133.3 | 133.3 | 135.2 | |
| D | 197.7 | 203.8 | 203.8 | 215.4 | 215.4 | 241.7 | 241.7 | 244 | |
| E | 108.5 | 108.5 | 108.5 | 108.5 | 108.5 | 123.5 | 123.5 | 123.5 | |
| F | 54 | 54 | 54 | 54 | 54 | 60 | 60 | 60 | |
| G | G3/4" | G3/4" | G3/4" | G3/4" | G3/4" | G1" | G1" | G1" | |
| Weight | kg | 9.3 | 10.3 | 10.3 | 11.5 | 11.5 | 14.5 | 14.5 | 14.5 |
| Quantity(Acres) | 1 - 10 | >10 |
| Est. Time(days) | 3 | To be negotiated |
