• Model NO.：045 Series(displacement: 630,800,1000,1250)
• Type：Hydraulic Power Units
• Transport Package：in Carton to Pallets
• Trademark：HYPHEN
• Origin：China
• HS Code：8412299090

Basic Info.

Model NO. 045 Series(displacement: 630/800/1000/1250) Type Hydraulic Power Units Transport Package in Carton to Pallets Trademark HYPHEN Origin China HS Code 8412299090

Product Description

045 series PSU is a flow amplifying PSU.
It has small displacement and low input torque at the low steering speed. At the quick steering speed, it has a large displacement.
The displacement includes: 630.800.1000.1250ml/r. It is typical used in heavier engineering vehicles.

Features:
1. The optimum design of spool and sleeve gains better characteristics.
2. Low hydraulic noise.
3. Special casting design for low pressure drop.
4. Basic system load sensing.

Main Specification Data:
Max. System pressure-16MPa
Max. Back pressure-2.1MPa
Input torque-2.8~4.0Nm
Max. System operating temperature-93° C
Recommended oil filtration-ISO 19/16
