• Model NO.：P05 P080 P07 P110 P09 P140 P12 P200 P16 P260
• Origin：China
• HS Code：8413606090
• Production Capacity：50

Basic Info.

Model NO. P05 P080 P07 P110 P09 P140 P12 P200 P16 P260 Origin China HS Code 8413606090 Production Capacity 50

Product Description

[Features]

Highest rated pressure of any
comparable pump available in
the market place today.
Full power through drive
capability allows two (2) pumps
of the same displacement to be
run in tandem at full rated pressure and flow, simultaneously.
Fast, compensator response
minimizes pressure overshoot.
Two stage, pilot operated compensator provides sharp pressure cutoff at compensator setting, typically regulating pressure within 50 psi (3.5 bar).
Compensator may easily be
remotely controlled or used in
load sensing circuits.
Precision barrel bearing
absorbs radial forces, allowing
longer operation at higher pressure and higher speeds.
Piston design minimizes
trapped oil volume to maximize
efficiency.
Angled barrel ports reduce the
piston circle diameter, which
allows oil to enter at reduced
velocity. This allows the pump
to run faster, with atmospheric
inlet pressure.
Spherical port plate and barrel
face provides support to barrel
to offset forces from angled
ports.
Large suction port reduces
inlet flow velocity to allow the
pumps to run at higher speeds
with atmospheric inlet.
Standard SAE split flange
with inch or metric bolts,
depending on pump version
(SAE or metric).
Conforms to SAE or ISO
mounting standards.
Damped low inertia rocker
cam allows very quick compensation, resulting in more stable
and quieter pump.
Heavy duty shaft bearing to
absorb side and thrust loads.
High pressure shaft seal
allows higher case pressure
without external leakage. Note:
it is always advisable to maintain the lowest possible case
pressure.
Drive shaft options include
keyed or splined in SAE, ISO
and DIN.
Optional controls
A wide variety of optional controls are available and are
designed with simplicity and a
maximum of common elements.
