Truck Dump System 1 Spool Air Shift Hydraulic Directional Valve

Shijiazhuang Hanjiu Technology Co., Ltd.
  • Function：Direction Control
  • Type：-
  • Transport Package：Carton Packing
  • Specification：DCV
  • Trademark：Hanjiu
  • Origin：China

Base Info

  • Model NO.：DCV200, DCV100
  • HS Code：84818029
  • Production Capacity：500000 Per Year

Description

Max Pressure315 bar/5076PSIControl Typepneumatic, (manual, pneumatic, hydraulic, electro-hydraulic available )Pneumatic control pressure5~10barOil port sizeas customizedSpool stroke±5mm





oil ports

BSP ThreadMetric threadUS standard UNF threadUS standard NTP threadcodeThread sizecodeThread sizecodeThread sizecodeThread sizeG04G1/4M16M16X1.5U105/8-12UNFN06NPT3/8G06G3/8M18M18X1.5U123/4-16UNFN08NPT1/2G08G1/2M20M20X1.5U147/8-14UNFN12NPT3/4G12G3/4M22M22X1.5U161-12UNF

Work sections: single acting air control spring return to center. Cylinder spool ( B port is blocked at center position)

Salami and Prince Hydraulic Valve replacement. Quality parts performance guaranteed. 1 year warranty.

Inlet: Side, Main relief: 2000PSI set. pressure adjustable, Outlet: Side.

The valve was assembled and tested.





This valve option might be not one you are looking for, just tell us what is exact you are looking. We will contact you to be sure to build a valve is exact one you need. then send buyer invoice.
