• Model NO.：MW2008
• Material：Carbon Steel
• Transport Package：Plywood Case
• Specification：2"x8"
• Origin：China
• HS Code：84122100

1.Rod End Cross TubeHigh tensile steel2.GlandDuctile iron ASTM A536 65-45-123.RodHigh tensile SAE C1045, ground & polished hard chrome plated rod4.Tube WeldmentHigh tensile cold drawn tube, precision honed for extended seal life5.Port PlugPlastic6.Grease FittingM6 (standard included)7.Base EndHigh tensile cast steel8.Piston nut                               Jam nut, grade 8, high tensile zinc-plated9.PistonDuctile iron ASTM A536 65-45-12, type A & type B piston availableA. Piston ID seal(B type piston)O-ring(1)+back up ring(2)A. Piston ID seal(A type piston)O-ring(1)+back up ring(2)B. Piston OD seal(B type piston)Bronze impregnated PTFE piston ring w/rectangular CS nitrile expanderB. Piston OD seal(A type piston)Polyurethane U-capC. Tube sealO-ring(1)+back up ring(1)D. Rod sealPolyurethane U-capE. WiperMetal canned wiper



•diameter of bore & rod
We can supply customized hydraulic cylinders with drawings or samples, or if you could provide following specification:Custom Hydraulic Cylinder

•stroke
•mounting style
•mounting distance
•working pressure
•ports
•seals
•special modifications.





Qingdao GD Machinery CO.,LTD.

Product

tie rod hydraulic cylinder, welded hydraulic cylinder, telescopic cylinders cylinder,

 flange type hydraulic cylinder,  hydraulic cylinder with valve function,

hydraulic power unit,  Hydraulic manifold block,  pneumatic fitting,

Material

Tube - Cold Drawn Precision seamless Tubing
End Caps - Steel, threaded fixed;
Wear Ring - Nylon Backup Washer
Rod Seals - Polyurethane U-Cap
Rod - Chromed, ground & polished piston rod

Mounts - Trunnion with angular Swivels
Rod Wiper - Polyurethane

Application

Agriculture, Concrete & Asphalt, Cranes, Fire & Rescue,

 Forestry & Logging,Mining & Rock Crushing,Oil & Gas,

Snow & Ice Control,Waste Management and Material Recycling Industry ,

 Engineering Equipment, Special Vehicle

Feature

1.High quality with a reasonable price

2.ISO9001-2008

3.Customized specification are accepted

Payment

T/T;L/C,WESTERN UNION.

Port

Shanghai, Qingdao

Quotation

According to the specific request

MOQ

According to the product

Packaging

metal case;plywood case;carton or as requirement

Delivery time

30days upon receipt of 30% deposit; or upon receipt of relevant L/C;



CONTACT:

Emma Hong





Please feel free to contact me at any time.
