China Blnce Om4 Low Speed High Torque Orbot Motor for Heavy Equipment

Dongguan Blince Machinery & Electronics Co., Ltd.
  • Number of Poles：4
  • Speed：Low Speed
  • Type：Hydraulic Power Units
  • Displacement(Cc/Rev)：250~650
  • Continuous Max Speed(Rpm)：315
  • Continuous Max Torque(N.M)：1000

Base Info

  • Model NO.：om4 series hydraulic motor
  • Max Pressure(MPa)：15
  • Cylinde Parallel Shaft Size：40mm
  • Hole Middle Distance：160mm
  • Ports and Drain Port：G1,4, G3,4
  • Flange：Standard 4 Hole Diamond Flange
  • Material：Rust-Proof Cast Iron
  • Warranty：One Year
  • Transport Package：Sale Packing Contians Carton or Wood Case
  • Specification：CE
  • Trademark：Blince
  • Origin：Guangdong Province, China (Mainland)
  • HS Code：8412291000
  • Production Capacity：1000 Units Per,Month

Description

TypeOM4
250
 OM4
315OM4
400OM4
500OM4
630Displacement (cm3/rev.)255.9316.1406.4489.2633Max.speed (rpm)cont.310250200155125int.390310240200155Max.
torque
(N?m)cont.5006307908601000int.6207808809501150Max.
Output
(KW)cont.1515131211int.1717161413Max. pressure
drop(MPa)cont.1515151412.5int.1818171514Max.flow (L/min)cont.2020202020int.2525252525Net Weight (kg)99.5101112
