Lsq-S8 Medium-Pressure High Performance Pneumatic and Hydraulic Quick Coupling (BRASS)
Zhejiang Songqiao Pneumatic & Hydraulic Co., Ltd.- From 1/4′ to 1"：All Threads Are Available
- Mechanical Connection：Locking Balls
- Interchangeability：ISO 7241 Series "B", Poppet Valve
- Working Pressures：1000 Psi
- Transport Package：Carton
- Origin：Zhejiang China
Base Info
- Model NO.：LSQ-S8 ( ISO B BRASS )
- HS Code：7307990000
- Production Capacity：100000 Set,Month
Description
LSQ-S8 Series Couplings feature:
1. Poppet valves available to prevent uncoupled leakage.
2. Poppet valves open automatically when coupled, within rated working pressure, to keep the flow expeditely.
3. Dependable ball-locking mechanism holds the mating halves together.
4. Socket and plug are precision machined from solid bar stock.
5. LSQ-S8 series conforms to the standard of ISO 7241-B.
6. Compatible with PARKER 60 Series, FASTER HNV Series, AEROQUIP FD45 Series and HANSEN HK Series
