030 Large Displacement Series Hydraulic Power Steering Unit
Wuxi Hyphen Technology Co., Ltd.- Hydraulic Valve：Switch Control Valve
- Auxiliary Components：Pipe and Pipe Fittings
- Hydraulic Fluid：Mineral Oil
- Flow Control Valve：Throttle Valve
- Pressure Control Valve：Sequence Valve
- Hydraulic Control Unit：Selector Valve
Base Info
- Model NO.：030 series (displacement: 630,800,1000ml,r)
- Hydraulic Motor：Piston Hydraulic Motor
- Hydraulic Actuator：Hydraulic Cylinder Piston
- Hydraulic Power Units：Gear Pump
- Type：Hydraulic Power Units
- Transport Package：in Cartons, Plywood Case, Plywood Pallets
- Specification：CE
- Trademark：hyphen
- Origin：Wuxi, Jiangsu, China
- HS Code：8412299090
- Production Capacity：5000000PCS
Description
Basic Info.
Model NO. 030 series (displacement: 630/800/1000ml/r) Hydraulic Motor Piston Hydraulic Motor Hydraulic Actuator Hydraulic Cylinder Piston Hydraulic Power Units Gear Pump Type Hydraulic Power Units Transport Package in Cartons, Plywood Case, Plywood Pallets Specification CE Trademark hyphen Origin Wuxi, Jiangsu, China HS Code 8412299090 Production Capacity 5000000PCSProduct Description
030 Series:
Large Displacement Series
Include: Open center and load sensing style.
Displacement: 630/800/1000ml/r
030 Large Displacement Series PSU:
030 series PSU is a large displacement PSU.
The displacement includes: 630.800.1000ml/r. It is typical used in heavier engineering vehicles.
Features:
1. The optimum design of spool and sleeve gains better characteristics.
2. Low hydraulic noise.
3. Special casting design for low pressure drop.
4.2 basic systems open center and load sensing.
Main Specification Data:
Max. System pressure-16MPa
Max. Back pressure-2.1Mpa
Input torque-2.8~4.0Nm
Max. System operating temperature-93° C
Recommended oil filtration-ISO 19/16
