020 Low Input Torque Series Hydraulic Power Steering Unit & 025 Ultra Low Input Torque Series Hydraulic Power Steering Unit

Wuxi Hyphen Technology Co., Ltd.
  • Certification：CE, ISO9001
  • Pressure：Medium Pressure
  • Work Temperature：Normal Temperature
  • Voltage：24V
  • Installation：Vertical
  • Material：Cast Steel

Base Info

  • Model NO.：020 Series(displacement:80,100,125,160,200,250,315
  • Type：Hydraulic Power Units
  • Transport Package：Carton
  • Specification：80-160
  • Trademark：hyphen
  • Origin：China
  • HS Code：87089490
  • Production Capacity：20000000

Description

Basic Info.

Model NO. 020 Series(displacement:80/100/125/160/200/250/315 Type Hydraulic Power Units Transport Package Carton Specification 80-160 Trademark hyphen Origin China HS Code 87089490 Production Capacity 20000000

Product Description

020 Low Input Torque Series Hydraulic Power Steering Unit & 025 Ultra Low Input Torque Series Hydraulic Power Steering Unit020 Low Input Torque Series Hydraulic Power Steering Unit & 025 Ultra Low Input Torque Series Hydraulic Power Steering Unit

020 Low Input Torque Series PSU & 025 Ultra Low Input Torque Series:
Many progress of design were taken in 020 series PSU. It is typical used in forklift, hydraulic rudder of ships.

Features:
1. The design of valve with optimum gains better characteristics.
2. Low hydraulic noise.
3. Low wheel slip.
4. Special casting design for low pressure drop.
5. Basic systems open center.

Main Specification data:
Max. System oressure-16MPa
Max. Back pressure-2.1MPa
Input torque-1.7~2.5Nm
Max. System operating temperature-93° C
Recommended oil filtration-ISO 19/16
