• Model NO.：OMP 80
• Type：Hydraulic Power Units
• Displacement：314.5cc
• Max. Speed：192rpm
• Max.Pressure：9MPa
• Max.Torque：375n.M
• Weight：6.9kg
• Max.Output：7.0kw
• Max.Flow：60L,Min
• Length：172mm
• Port：G1,2
• Warranty：One Year
• Transport Package：Plastic Tube +Carton+Wooden Pallets
• Specification：CE, CCC, ISO
• Trademark：Blince
• Origin：Guangdong, China
• HS Code：8412291000
• Production Capacity：500sets,Month

Basic Info.

Model NO. OMP 80 Type Hydraulic Power Units Displacement 314.5cc Max. Speed 192rpm Max.Pressure 9MPa Max.Torque 375n.M Weight 6.9kg Max.Output 7.0kw Max.Flow 60L/Min Length 172mm Port G1/2 Warranty One Year Transport Package Plastic Tube +Carton+Wooden Pallets Specification CE, CCC, ISO Trademark Blince Origin Guangdong, China HS Code 8412291000 Production Capacity 500sets/Month

Product Description

                                  OMP Series Hydraulic Motor
OMP series high speed motors are small volume, economical type,which is designed with shaft distribution flow, which
adopt the Gerotor gear set design and provide compact volume, high power and low weight.

Characteristic features of OMP high speed hydraulic motor
* Advanced manufacturing devices for the Gerotor gear set, which provide small volume, high efficiency and long life.
* Shaft seal can bear high pressure of motor of which can be used in parallel or in series.
* Advanced construction design, high power and low weight.



Applications : Hydraulic motors are ideally suited for Applications demanding vary high Torque at low or variable
speeds, along with economy, compact size, reliability, maintenance-free service etc. These motors also provide a cost
effective alternative to many other variable speed drives in vogue.

Warranty:
1. Guarantee for one year or 1000 hours (according to whichever ends first) from the purchasing date on.
2. During the guarantee period, our company will provide the easy-damaged spare parts for problems caused by our
 quality of production or raw material. Pls provide the defective appearance and related invoice number.
3. Sorry for you should responsible for the freight come-and-go,and the custom tax.
4. After expiration, our company can provides cost spare-parts maintenance for engines.
5. To save the cost,you can choose send the motor back without packing.
6. My dear friend, your emails can be get within one business day. If you do not receive our reply, please kindly
re-sent your email or give us a call any time.

Company Information:
    Established in 2004, Dongguan Blince Machinery & Electronics Co., Ltd. Specializes in the business of hydraulic
motor, cycloid motor, vane pump and hydraulic valve.Located in Changan, Dongguan, Guangdong,  where we enjoy
the convenient access to major transportation networks. Our factory covers an area of 30,000 square meters and has
about 361 staffs. Furthermore, our engineers have decades of experience in hydraulic area, all the products are
manufactured with advanced equipment and strict QC procedures in order to ensure high quality. Copperate with us,
you will have the stably, timely and credible supply.

Have any Questions, welcome to contact Sali, I'm gald to service you in Model selection giude!
