Omp 125cc High Speed Hydraulic Motors for Sale Hydraulic Motor Price
Dongguan Blince Machinery & Electronics Co., Ltd.- Certification:CE, ISO9001
- Power Rating:12kw
- Speed:High Speed
- Type:Hydraulic Motor
- Displacement:314.5
- Max. Seed:192
Base Info
- Model NO.:OMP 36,50,80,100,125,160,200,250,315,400,500
- Max.Torque:375
- Max.Output:7.0
- Max.Pressure:9
- Max.Flow:60
- Weight:6.9
- Length:172
- Warranty:One Year
- Transport Package:Plastic Tube +Carton+Wooden Pallets
- Specification:CE, CCC, ISO
- Trademark:Blince
- Origin:Guangdong, China
- HS Code:8412291000
- Production Capacity:500sets,Month
Description
TypeOMP
36 OMP
50 OMP
80 OMP
100 OMP
125 OMP
160 OMP
200 OMP
250 OMP
315 OMP
400 OMP
500 Geometric displacement
(cm3/rev.) 36 51.7 77.7 96.2 120.2 157.2 194.5 240.3 314.5 389.5 486.5 Max.speed (rpm) con. 1500 1150 770 615 490 383 310 250 192 155 120
int. 1650 1450 960 770 615 475 385 310 240 190 150 Max.torque (N.m) cont. 55 100 146 182 236 302 360 380 375 360 385
int. 76 128 186 227 290 370 440 460 555 525 560
peak 96 148 218 264 360 434 540 550 650 680 680 Max.output (KW) cont. 8.0 10.0 10.0 11.0 10.0 10.0 10.0 8.5 7.0 6.0 5.0
int. 11.5 12.0 12.0 13.0 12.0 12.0 12.0 10.5 8.5 7.0 6.0 Max.pressure
Drop (Mpa) cont. 12.5 14 14 14 14 14 14 11 9.0 7.0 6.0
int. 16.5 17.5 17.5 17.5 17.5 17.5 17.5 14 14 10.5 9.0 Max.flow (L/min) cont. 55 60 60 60 60 60 60 60 60 60 60
int. 60 75 75 75 75 75 75 75 75 75 75 Net Weight(kg) 5.6 5.6 5.7 5.9 6.0 6.2 6.4 6.7 6.9 7.4 8.0
Warranty:
1. Guarantee for one year or 1000 hours (according to whichever ends first) from the purchasing date on.
2. During the guarantee period, our company will provide the easy-damaged spare parts for problems caused by our
quality of production or raw material. Pls provide the defective appearance and related invoice number.
3. Sorry for you should responsible for the freight come-and-go,and the custom tax.
4. After expiration, our company can provides cost spare-parts maintenance for engines.
5. To save the cost,you can choose send the motor back without packing.
6. My dear friend, your emails can be get within one business day. If you do not receive our reply, please kindly re-sent.
