Green Valve Replacement 2 Section Dcv Valve 200 Lpm for Loader Lift Bucket
Shijiazhuang Hanjiu Technology Co., Ltd.- Function：Direction Control
- Type：-
- Transport Package：Carton Packing
- Specification：2P80
- Trademark：Hanjiu
- Origin：China
Base Info
- Model NO.：2P80
- HS Code：84818029
- Production Capacity：500000 Per Year
Description
Basic Info.
Model NO. 2P80 HS Code 84818029 Production Capacity 500000 Per YearProduct Description
Green valve replacement 2 Section valve 200 LPM for Loader Lift & BucketModel: DCV200/2
This sectional valve is a hydraulic directional control valve. These valves are used to start and stop fluid flow into hydraulic cylinders or hydraulic motors.
Fast review:
2 Section valve. one With Float, section 2 with Standard Spring center.One float for loader lift // One magnetic kick out for bucket level.Port relief Section one 3000 PSI A & BSection two 2000 PSI A & BPower Beyond
Benefits:
2 Spool valve with compact design allows for installations in tight areas
Precision ground and hard chrome-plated spools assure a long life
High-tensile strength cast iron monoblock construction
SAE O-Ring ports ensure solid seal and prevent blockages
Capable of closed center or Power Beyond (conversion plug required)
Adjustable Relief Valve Range: 1500 to 3625 PSI
Preset Pressure Relief: 2610 PSI
