Orbit Hydraulic Motor Charlyn 6000 Series 112-1067-006 Aftermarket

Shijiazhuang Hanjiu Technology Co., Ltd.
  • Certification：CE, ISO9001
  • Type：-
  • Transport Package：Carton Packing
  • Specification：112-1067-006
  • Trademark：Hanjiu
  • Origin：China

Base Info

  • Model NO.：112-1067-006
  • HS Code：84122910
  • Production Capacity：500000 Per Year

Description

FeatureCodeDescriptionPRODUCTMMOTORSERIES066000 SERIESDISPLACEMENT239391.7 CM3/R [23.90 IN3/R]MOUNTING TYPEABSTANDARD; (SAE CC); 4 BOLT; 127.0 [5.00] PILOT DIA. 14.35 [.565] DIA. HOLES ON 162.0 [6.38] DIA. BOLT CIRCLEOUTPUT SHAFT0138.10 [1.500] DIA. STRAIGHT SHAFT WITH .375-16 UNC-2B THREAD IN END; 9.52 [.375] SQ X 41.28 [1.625] STRAIGHT KEYPORTSAA1.3125-12 UN-2B SAE O-RING PORTS - STAGGERED PORTSCASE FLOW OPTIONS02.4375-20 UNF-2B SAE O-RING PORT WITH CHECK VALVELOW PRESSURE RELIEF0NONEPRESSURE/FLOW OPTION00NONEGEROLER OPTION0STANDARDSEAL OPTION0STANDARD





We provide hydraulic drive engine for crushers, screens and other quarrying and mining machinery. We provide the most accurate and lasting solutions to our customers' needs and expectations. We make our friendship with the service that we offer by keeping customer satisfaction on top of everything.
