China Mini Orbital Motor Omp BMP 200cc Hydraulic Engine

Dongguan Blince Machinery & Electronics Co., Ltd.
  • Certification：CE
  • Power Rating：12kw
  • Number of Poles：2
  • Speed：High Speed
  • Type：Omp Hydraulic Motor
  • Displacement(Cc/Rev)：200cc

Base Info

  • Model NO.：Omp200 Hydraulic Motor
  • Continuous Max Speed(Rpm)：310
  • Continuous Max Torque(N.M)：360
  • Hole Middle Distance：106.4mm
  • Cylinde Parallel Shaft Size：25mm
  • Flange：Standard 2 Hole Diamond Flange
  • Max Pressure(MPa)：14
  • Ports and Drain Port：G1,2, G1,4
  • Material：Rust-Proof Cast Iron
  • Hydraulic Power Units：Gear Pump
  • Auxiliary Components：Hydraulic Motor
  • Flow Control Valve：Hydraulic Motor
  • Pressure Control Valve：Orbital Motor
  • Hydraulic Motor：Omp Hydraulic Motor
  • Hydraulic Actuator：Hydraulic Motor
  • Transport Package：Sale Packing Contians Carton or Wood Case
  • Specification：CE
  • Trademark：Blince
  • Origin：Guangdong Province, China (Mainland)
  • HS Code：8412291000
  • Production Capacity：1000 Units Per,Month

Description

      typeOMP
OMPH
36OMP
OMPH
50OMP
OMPH
80OMP
OMPH
100OMP
OMPH
125OMP
OMPH
160OMP
OMPH
200OMP
OMPH
250OMP
OMPH
315OMP
OMPH
400OMP
OMPH
500Geometric displacement3651.777.796.2120.2157.2194.5240.3314.5389.5486.5Max.speed.(rpm)con.15001150770615490383310250192155120int.16501450960770615475385310240190150Max.torque(N.mcont.55100146182236302360383375360385int.76128186227290370440460555525560Max.output(KW)cont.8.010.010.011.010.010.010.08.57.06.05.0int11.512.012.013.012.012.012.010.58.57.06.0Max.pressure
Drop(Mpa)cont.12.514141414141411976int16.517.517.517.517.517.517.5141410.59Max.flow(L/min)cont.5560606060606060606060int.6075757575757575757575OMP50-2AD   (OMP-1510310)   OMP50-2AD   (OMP-1510610)OMP50-2CD   (OMP-1510300)  OMP50-2CD   (OMP-1510600)OMPH50-H2RS (OMP-1517041)  OMP50-2ED   (OMP-1510330)OMP50-2ED   (OMP-1510630)  OMP50-4BD   (OMP-1515001)China Mini Orbital Motor Omp BMP 200cc Hydraulic Engine
China Mini Orbital Motor Omp BMP 200cc Hydraulic Engine
China Mini Orbital Motor Omp BMP 200cc Hydraulic Engine
China Mini Orbital Motor Omp BMP 200cc Hydraulic Engine
China Mini Orbital Motor Omp BMP 200cc Hydraulic Engine

Blince manufactured factory estblish in 2004s , we are full experience to technical adis for hydraulic motor omr /omrs/omm /omp/omph/omt/omv/oms/omsy/ok/oz/ 6kseries  & vane pump( PV2R, VQ ,V ,SQP Series.pump cartridge)
We own ourself brand  in 2010 years "blince" ,to enlarge  name plate efforts ,also support customization
Our order track information " &  perfomance certificate . please entre in the "company profile part " to seek

Contact detail as follows
