• Model NO.：LPD360A1
• Fluid：water,beer,coffee,juice
• Voltage Type：DC & AC
• Available Voltage：12,24,42,60,96,110,180,205,220,380
• Weight：100g
• Transport Package：Cartons and Pallets
• Specification：1,4
• Trademark：Longli
• Origin：China
• HS Code：8412299090
• Production Capacity：10000PCS,Month

Basic Info.

Model NO. LPD360A1 Fluid water,beer,coffee,juice Voltage Type DC & AC Available Voltage 12,24,42,60,96,110,180,205,220,380 Weight 100g Transport Package Cartons and Pallets Specification 1/4 Trademark Longli Origin China HS Code 8412299090 Production Capacity 10000PCS/Month

Product Description

Normally Open Miniature Water Solenoid Valve



Normally Open Miniature Water Solenoid Valve usually be used in water purifier for water inlet and waste water control through 12V 24VDC 110V 220VAC direct current to control the on and off of valve. Using with the high or low pressure switch or mini computer control box to rule the the electronic parts to reach the function that water flowing is up to the power. It can control the flow of fluid using the flow of electrons! This liquid valve would make a great addition to your robotic gardening project. There are two 1/4" (Nominal non-taped National Pipe) outlets. Normally, the valve is open. When 12V 24VDC 110V 220VAC is applied to the two terminals, the valve closed and water can be stopped. The valve has a gasket arrangement inside, so there is a minimum pressure requirement of 0.02 Mpa (3 PSI). Also, liquid can only flow one direction.

1/4" Nominal quick connector
Working Pressure: 0.02 Mpa - 0.8 Mpa
Working Temperature: 1 ºC - 75 ºC
Response time (open): ≤ 0.15 sec
Response time (close): ≤ 0.3 sec
Actuating voltage: 12V 24VDC 110V 220VAC 50/60Hz
Actuating life: ≥ 100000 cycles
Weight: 100g

Why Choose Us
1. With 30 years experience of hydraulic components in china.
2. Best manufacturing machinery, quality level, best price, best service.
3. We have very good and comprehensive after-sales service.
4. We have no MOQ for clients and tailor0made to clients request for our huge inventory.

Our Service
Pre-sale service: we provide presales in our first cooperation make clear your situation and give you some advice.
In-sale Service: We will track the production progress and quality, check the exact model and quantity one by one before delivering.
After-sale Service: We will provide a one year free warranty and lifetime maintenance. We will change all questions in 7*24hours if you buy from us.

Packing
Eternal Brand, Neutral or Customer's requires label.
Neutral carton or same as the Customer's requires, export standard carton.
All cartons should be packed into the pallets more carefully.
All of the productions are inspected carefully one by one by QC before delivery.

Payment term:
T/T 50% as deposit in advance, the balance should be paid before delivery.100% L/C is acceptable. Western Union and PayPal is acceptable.
Transportation: By sea; By air; By truck; By express (DHL,TNT,UPS,FEDEX)
Trading term: FOB,CFR,CIF
